| Module Specifications | ||
| Pixel pitch (mm) | 6 | 8 |
| Pixel Configuration | Nationstar SMD2727 | Nationstar SMD3535 |
| Module Resolution (W*H dots) | 32*32 | 32*16 |
| Module Pixels (dots) | 1024 | 512 |
| Module Size (W*H mm) | 192*192 | 320*160 |
| Cabinet Parameters | ||
| Cabinet Configuration (Module quality W*H) | 6*6 | 3*6 / 4*8 |
| Cabinet Size (W*H mm) | 1152*1152 | 960*960 / 1024*1024 |
| Module Quality (pcs) | 36 | 18 / 32 |
| Cabinet Pixels (dots) | 36,864 | 14,400 / 16,384 |
| Pixel Density | 27,889 dots/m2 | 15,625 dots/m2 |
| Material | Aluminum | |
| Cabinet Weight (kg/sqm) | 32.8 | 36 / 32.8 |
| One Screen Parameters | ||
| Brightness | 6,000 nits | |
| Contrast Ratio (Max./Min.) | 8,000 | |
| Driving Method | 1/8 Scanning | |
| View Angle | Horizontal 160° / Vertical 120° | |
| Min Viewing Distance | 6 m | 8 m |
| Grayscale Intensity | 16 bit | |
| Color Depth | 16 bit | |
| Refresh Rate | 3,840 Hz | |
| Screen Wiring | Gold Wiring | |
| Frame Frequency | 50 -- 60 Hz | |
| Input Voltage | AC220V/50Hz | |
| Defects Rate | <= 0.00001 | |
| Power Consumtion | Max: 780/m3 Average:280W/m3 | |
| Cabinet Weight | 32.8 kg/sqm | |
| MTBF | >10,000 hours | |
| Life Span | >= 100,000 hours | |
| Module Display Brightness Uniformity | < 3% | |
| Earth Leakage Current | < 3 mA | |
| Protective Grade | IP65 Front / IP54 Back | |
| Temperature-operating | -20°C ~ 65°C | |
| Humidity-operating | 10% ~ 95% | |
