| Pixel Pitch | 3mm |
| LED Type | SMD2020 Kinglight |
| Module Resolution | 64 dots x 64 dots |
| Driving Mode | 1/16 scan |
| Module Pixels | 4,096 dots |
| Module Size | 192mm x 192mm |
| Cabinet Size | Customized based on module size (Thickness 115 mm) |
| Cabinet Resolution | Based on cabinet size |
| Pixel Density | 110,889dots/㎡ |
| Best Viewing Distance | ≥3m |
| Brightness | 800-1000nits |
| IP Grade | IP43 |
| Refresh Rate | 16:9 |
| Gray Scale | 3,840Hz |
| LED Type | 14bits~22bits(depends on IC driver and controller solution ) |
| Viewing Angle | H:160° / V:110° |
| Maximum Power Consumption/td> | 450W/ ㎡/td> |
| Average Power Consumption | 160W/ ㎡ |
| Screen Lifespan | ≥100,000 hours/td> |
| Input Voltage | AC220V @ 60Hz |
| Operating Temperature | -20℃~50℃ |
| Operating Humidity | 10%~90% |
| Cabinet Material | Steel |
| Cabinet Weight | 20kg/sqm |
| Operating System | Windows (Win7, Win10, etc .) |
| Signal Source Compatibility | DVI,HDMI1.3,DP1.2,SDI,HDMI2.0,etc . |
