| Item | P3.9 | P4.8 | P6.25 | P7.8 | P10.4 |
| Pixel Pitch | 3.906mm | 4.807mm | 6.25mm | 7.8125mm | 10.417mm |
| LED Type | SMD1921 | SMD1921 | SMD2727 | SMD2727 | SMD2727 |
| Module Resolution | 128 × 64dots | 104 × 52dots | 80 × 80dots | 64 × 32dots | 48 x 24dots |
| Driving Mode | 1/16scan or 1/8scan | 1/13scan or 1/7scan | 1/7scan | 1/7scan | 1/7scan |
| Module Pixels | 8,192dots | 5,408dots | 6,400dots | 2,048dots | 1,152dots |
| Module Size | 500 × 250mm | ||||
| Cabinet Size | 1000×1000mm & 1000×500mm | ||||
| Cabinet Resolution | 256 × 256dots | 208 × 208dots | 160 × 160dots | 128 × 128dots | 96 × 96dots |
| Pixel Density | 65,536 dots/m² | 43,264 dots/m² | 25,699 dots/m² | 16,384 dots/m² | 9,216 dots/m² |
| Minimum Viewing Distance | ≥3.9 m | ≥4.8 m | ≥6m | ≥7.8m | ≥10.4m |
| Brightness | 6,000-8,000 nits (up to 10,000 nits for special custom model) | ||||
| IP Grade | IP66 | ||||
| Refresh Rate | 1,920Hz～3,840Hz | ||||
| Gray Scale | 14bits～22bits | ||||
| Viewing Angle | H:160° / V:160° | ||||
| Power Consumption | 500W/m²(MAX) 200W/m²(Average) | ||||
| Input Voltage | AC110V～AC220V @ 50Hz / 60Hz | ||||
| Operating Temperature | 20℃～65℃ | ||||
| Operating Humidity | 10%～90% | ||||
| Cabinet Material | Aluminum | ||||
| Cabinet Weight | 25 kg/m² | ||||
| Control System | Novastar/Linsn/Colorlight,etc | ||||
| Signal Source Compatibility | DVI, HDMI, DP, SDI, etc. | ||||
