| Model | VEGA120 | VEGA136 | VEGA163 | VEGA220 |
| Diagonal | 120 inch | 136 inch | 163 inch | 220 inch |
| LED pitch | P1.58 | P1.8 | P1.8 | P2.5 |
| LED type | SMD1010 GOB | SMD1010 GOB | SMD1010 GOB | SMD1515 |
| Screen Size (mm) | 2600x1842 | 3030x2502.5 | 3630x2840 | 4924.6x2896.2x39 (90 with Bracket) |
| Display Size (mm) | 2600x1730 | 3030x1812.5 | 3630x2150 | 4876.8x2743.2 |
| Weight (kg) | 95 | 140 | 190 | 488 |
| Display Ratio | 16:9 | |||
| Resolution (px) | 1920x1080 | |||
| Gray Scale | 12/14/16 | |||
| Refresh Rate (Hz) | 1920/2880/3840 | |||
| Brightness (nits) | 550 | 600 | 600 | 600 |
| Viewing Angle (deg) | 170 | |||
| Contrast Ratio | 8000:1 | |||
| Colour Gamut | 110%NTSC | |||
| Voltage (V) | 110~240V | |||
| Avg. Power Consumption (KW) | 1.65-2.60 | 0.76 | 0.83 | 1.47 |
| Max. Power Consumption (KW) | 5.00 | 2.28 | 2.49 | 6.03 |
| OS | Android (Standard) | |||
| Interface Type | USB3.0xUSB2.0x3 / HDMIx4 / 3.5mm TRS | |||
| Video Processor | NOVA MEE210 | |||
| Hardware Confogiration | CPU 64-bit quad-core 1.7 GHz processor / RAM DDR-4GB / GPU Mail T820 / ROM 8GB eMMC5.1 (Standard) | |||
| IP Rate | IP31 | |||
| Recommended Viewing Distance (m) | 1.3 | 1.6 | 1.8 | 2.5 |
