| Specs | P0.9 | P1.2 | P1.5 |
| Pixel Pitch | 0.9375mm | 1.25mm | 1.5625mm |
| LED Type | Mini LED (Nationstar) | SMD1010 (Nationstar) | SMD1212 (Nationstar) |
| Module Dimension (mm) | 300*168.75 | 300*168.75 | 300*168.75 |
| Cabinet Dimension (mm) | 600*337.5 | 600*337.5 | 600*337.5 |
| Cabinet Resolution | 640*360 | 480*270 | 384*216 |
| Cabinet Material | die cast alu | die cast alu | Die cast alu |
| Cabinet weight | 4.8kgs | 4.8kgs | 4.8kgs |
| Maintenance way | Front | Front | Front |
| Brightness | 8,00-1,000nits | 8,00-1,000nits | 8,00-1,000nits |
| Refresh Rate | 3,840Hz | 3,840Hz | 3,840Hz |
| Scan Mode | Jan-60 | Jan-45 | Jan-36 |
| Gray Scale | 16bit | 16bit | 16bit |
| Contrast | 8,000:1 | 8,000:1 | 8,000:1 |
| Viewing Angle | 160°/160° | 160°/160° | 160°/160° |
| Input Voltage | AC110/240V | AC110/240V | AC110/240V |
| Lifespan (hrs) | ≥100,000 | ≥100,000 | ≥100,000 |
| MTBF (hrs) | >10,000 | >10,000 | >10,000 |
